Manger MSS P2 – Passive Floorstanding Loudspeakers
两路被动式座地扬声器 2-way PASSIVE

单元 Drivers:
– 高音 HF: MSW (80Hz- 40KHz), risetime 13μs
– 低音 LF: 8″ patented Carbon fiber foam membrane, Sandwich layer design
– 低音 Two passive radiators
分频点: Crossover Frequency: 340Hz.
Mundorf & Audyn parts

密封式声箱 Cabinet: Closed + Two passive radiators
频率表现 Freq. response: 30Hz-40KHz
阻抗 Impedance: 8 Ω
效率 Sensitivity: 89 dB (1W/1m)
接驳 Connectors:2pairsWBTNextGen® (Hi-Mid&LowFreq.)
尺寸 Dimensions (HxWxD): 1139x270x214 mm
重量 Weight: 32 kg

Manger MSS P1 – Passive Floorstanding Loudspeakers
两路被动式座地扬声器 2-way PASSIVE

单元 Drivers:
– 高音 HF: MSW (80Hz- 40KHz), risetime 13μs
– 低音 LF: Woofer 210mm. Special coated carbon fiber paper cone
分频点: Crossover Frequency: 350Hz.
Mundorf & Audyn parts

密封式声箱 Cabinet: Closed
频率表现 Freq. response: 40Hz-40KHz
阻抗 Impedance: 4 Ω
效率 Sensitivity: 88 dB (1W/1m)
接驳 Connectors:2pairsWBTNextGen® (Hi-Mid&LowFreq.)
尺寸 Dimensions (HxWxD): 1139x270x214 mm
重量 Weight: 28 kg

Manger MSS Z1 – Passive Bookshelf Speakers
两路被动式书架扬声器 2-way PASSIVE Monitor

单元 Drivers:
– 高音 HF: MSW (80Hz – 40 KHz), risetime 13μs
– 低音 LF: Woofer 210mm. Special coated carbon fiber paper cone.
分频点 Crossover frequency: 360Hz.
Mundorf & Audyn parts

密封式声箱 Cabinet: Closed
频率表现 Freq. response: 40Hz-40KHz
阻抗 Impedance: 4 Ω
效率 Sensitivity: 88 dB (1W/1m)
接驳 Connectors:2pairsWBTNextGen® (Hi-Mid&LowFreq.)
尺寸 Dimensions (HxWxD): 534x270x364 mm
重量 Weight: 26 kg

Manger MSMs1 –  Floorstanding Reference Active System
两路主动式座地扬声器 2-way ACTIVE – Brochure download

– 高音扩大器 HF: 180 W
– 低音扩大器LF : 250 W
单元 Drivers:
– 高音 HF: MSW (80Hz – 40 KHz), risetime 13μs
– 低音 LF: Woofer 200mm fibreglass-Polyester sandwich
分频点 Analog Electronic X-over: 330Hz
密封式声箱 Cabinet: Closed
频率表现 Freq. response: 30Hz-40kHz
接驳 Input: XLR (10kΩ)
最大音压 Max SPL: 110 dB
尺寸 Dimensions: 1139x270x214 mm / 重量 Weight: 42 kg

Manger MSS W1 – Wall Mount Home Theatre Speakers
1-way PASSIVE Monitor “On-Wall”

高音 HF: MSW (120Hz – 40kHz), risetime 13μs
密封式声箱 Cabinet: Closed
频率表现 Freq. response: 120Hz-40kHz
效率 Sensitivity: 90 dB (1w/1m)
接驳 Connectors: 1 pair binding-post
尺寸 Dimensions (HxWxD): 264x128x436 mm / 重量 Weight: 9 kg

Manger MSMc1 – Active Reference Bookshelf Studio Monitors
两路主动式书架扬声器 2-way ACTIVE – Brochure download

– 高音扩大器 HF: 180 W
– 低音扩大器 LF: 250 W

单元 Drivers:
– 高音 HF: MSW (80Hz – 40kHz), risetime 13μs
– 低音 LF: Woofer 200mm fibreglass-Polyester sandwich
分频点 Analog Electronic X-over: 330Hz
密封式声箱 Cabinet: Closed
频率表现 Freq. response: 30Hz-40kHz
接驳 Input: XLR (10kΩ)
最大音压 Max SPL: 110 dB
尺寸 Dimensions (HxWxD): 495x270x424 mm / 重量 Weight: 30 Kg

MSM C1 Fixed stand : Height: 620 mm or 880 mm
MSM C1 Lift stand : Height: Adjustable between 780 mm& 1080 mm

Manger MSMc1 with LF woofers – Active Reference Bookshelf Studio Monitors
MSM C1 L.F. Module: – Brochure download

Passive woofer module (max. SPL +6dB)
接驳 To be connected to MSMc1 back amplifier output No extra-amp. required
尺寸 Dimensions (HxWxD): 264 x 270x 343mm / 重量 Weight: 11kg

MSM C1 Fixed stand : Height: 620 mm or 880 mm
MSM C1 Lift stand :Height: Adjustable between 780 mm& 1080 mm

自订颜色服务。1625种RAL (http://www.ralcolor.com) 颜色任你选择,不另加收费。还有两种Matt(哑色)及High Gloss钢琴抛光版本。上图黑色的是哑色,橙黄这对是High Gloss RAL1028 (Melon yellow)。

如果阁下有兴趣我们产品的价格,可以到我们最新香港价格表
